5.5m/220kg Line Array Towerlift – Black

Description
The TL-A220 towerlift has been designed for lifting line array audio systems from the ground and keep them fix at high altitude. It has 2 special aluminum straps fixed from the legs to the aluminum base section to reinforced the body of the lifter.

This lifting tower is very compact and easy to handle, it has 4 swivel wheels at the base. It has powerful stabilizers in the legs, to level the lifter in difficult terrains, with slight slope. Black finish, with epoxy powder paint to the oven, which offers great resistance (The towerlift can be painted in the desired color, under prior request). It has two adjustable steel load forks that support the load, either supported on top of it, or hung underneath.

The TL-A220 features the ALS Red locks of VMB, which automatically blocks each section while lifting. And the inertial pendulum ILS safety system for the aluminum lifting carriage. It also has the special SRS Retentor system, patented by VMB, which guarantees that the towerlift will raise the aluminum sections orderly and automatically.
Package length (mm)

Package depth (mm)

Package height (mm)

Weight of the packed product (kg)

Cubic volume (m³)

Description

TECHNICAL SPECIFICATIONS
Maximum Height5.5m (18’)
Maximum Load220kg (485lb)
SafetyALS (Auto Lock Security)
Work Surface2.1 x 1.6m (6.9 x 5.2’)
Folded Height1.72m (5.6’)
Winch900kg
Adaptor Forks750mm Line Array Forks included
Weight111kg (244.7lb)
Title Type Size
TL-A220 5.5m/220kg Line Array Towerlift BGV-C1 Certificate application/pdf 119 KB
TL-A220 5.5m/220kg Line Array Towerlift Operating Instructions User Manual application/pdf 4 MB
