LED Groundstack 1.0m Linear Truss-Black

Description
Building your LED screen from ground level is now easy, whatever screen type/brand you use, Prolyte offers a universal solution, the LED Stack system. This combination of a base-unit, connection bar and ladder truss, creates a very stable system to support your LED screens in various configurations and offers flexibility in height as well as width.

A side entry clamp with the universal connection plate mounted makes it possible to mount almost any type of LED panel quick and easy.

By using longer connection bars, you can easily extend you screen with another row of panels.

Using the adjustable feet in the front and back of the base-unit, you can safely level the system, so your screen is completely levelled.
Cubic volume (m³)

Description

TECHNICAL SPECIFICATIONS
All components come standard black powder coated steel
Base unit1000mmL x 300mmD (50x50mm steel RHS)
Coupling systemProlyte CCS6 Conical Connector
Adjustable spindlesM12 (up to 70mm height adjustment)
Ladder style truss straight bracing30mmØ x 3mm Tube
Connection bar50x50x4mm Steel RHS
