RackMate 19"

RackMate 19″

SKU: AL-RM-UMC08AD-4F

  • Flexible Control Options: Available for direct control or low-voltage hoists with individual hoist operation via wired or optional wireless remote.
  • Channel Configurations: RackMate is available in 8, 12, 16, and 24 channel LV models, each featuring a phase reversal switch, 16-pin Harting connectors (2 to 6 depending on configuration), a non-linkable design, a 15m cabled remote control, and 19” rack mount format.
  • Robust Electrical Setup: 400–415V, 3-phase, 50–60Hz power supply with automatic phase alignment; multiple plug options including 32A CEE, 230V single-phase, SOCAPEX, and Harting.
  • Safety & Reliability: 1 circuit breaker per 4-hoist group, E-Stop, reset button, and optional HF wireless remote for secure operation.
  • Expandable & Customizable: Supports up to 20kW (optionally 40kW), daisy-linking controllers, optional wired remote, and variable link cable lengths for versatile setups.
Add to Quote Request
SKU: AL-RM-UMC08AD-4F Category: Brand:

Description

-Available for direct control or low voltage hoist -Available with 8 and 12 channels -Power supply 400-415V/3 phases/50-60 Hz – Power-in plug 32 A 5 poles CEE – Remote control with individual control of each hoist (Cable 15m) , E/S button and reset button – Remote Connection via SOCAPEX plug – Hoist Connection via Harting 16 ou SOCAPEX plug – Additional plug 32A out (back plate) – Plug 230V Single phase (back plate) – Automatic Phase alignment -Steel cabinet rack 19’’ (3U 8 channels, 6 U 12 channels) – 1 circuit breaker per group of 4 hoists. -Max. cumulated power 20kW): Mean 32A in total of all channel. Options: -63A for for cumulated power on all channel up to 40 kW (30mA delivered as standard) -HF Wireless remote 8 channels -Optional link card (LINK) for Daisylink in bewteen controler or / and wired remote -Optional wired remote (Yellow Pickle) with Up, Down and E-Stop -Wide range of lenght for link cable between remote and controler
