F32 Flat Truss 4 Way Universal Box Junction with 4 x Half-Spigots, Pin & R-Clips for 2 faces; M12 Bolt

Name: F32 Flat Truss 4 Way Universal Box Junction with 4 x Half-Spigots, Pin &amp; R-Clips for 2 faces; M12 Bolt
SKU: GT-F32JBOX
Availability: InStock

SKU: GT-F32JBOX

F32 Truss is a medium-duty flat or “ladder” style truss that is 290mm wide OD with 50mmø chords. Flat Truss is quite strong in the vertical plane but, with only two chords, it does not offer a lot of resistance in the lateral plane without amy bracing.

When bracing is used, however, F32 Flat Truss can provide a surprisingly strong yet lightweight grid solution. It is suited for use in theatres, clubs, houses of worship, conference centres, schools and other buildings such as suspending curtains/drapes, bracing, lighting and cable reticulation. Versatility is assured by the range of straight lengths, junctions and radials on hand.

A great number of 50mmø accessories are compatible with F32 Flat Truss. Custom components can be designed by the DQ team and made to order.

Product: GT-F32JBOX Categories: F32 Flat Truss Horizontal Junctions, F32 Flat Truss Vertical Junctions, F32 Flat Truss, Global Truss Tags: stage lighting truss systems, lighting truss dj, Cube, Concert Truss, design quintessence, stage light trusses, 290 Ladder Truss, Flat Truss, global truss catalog, titanav, lighting truss parts, AV Truss, dj city, stage lighting mounting bars, FD32, Ladder Truss, global truss distributor, titanav truss, globaltruss, lighting truss system price list, Truss Grid, dq, stage lighting rig, HD32, lighting truss, Theatre Truss, global truss f34 load data, truss coupler clamp, Cosmic Truss, 50mm truss clamp, lighting truss with lights, Lighting Grid, entertainment lighting, stage lighting truss design, Flat Truss 290, truss, Space Frame, global truss f44, truss lighting systems, Prolyte, Clamps, lighting trusses, Lighting Bar, entertainment production, stage lighting trusses, global truss, Touring Truss, global truss for sale, truss plate, Bolt Truss, Couplers, phantos, Truss Tube, entertainment rigging, stage truss design, stage truss, PRT, global truss pinnex, truss structures, 300mm Truss, DNA truss, pre-rig truss, Lighting Tube, entertainment rigging australia, stage truss manufacturers, GT F32JBOX, alutruss, Truss Circle, light truss, when is a rigger required, Plus Truss, Stage clamps, production, Circus Truss, entertainment rigging companies, stage truss systems, F32-4 Way, stage lighting truss, Truss Hinge, lighting clamps, Alloy Truss, Truss Australia, rigger course, Custom Truss Box Truss, event rigging, stage trusses, square truss, Tent Truss, lighting trigger clamps, Aluminium Truss, audio brisbane, rigging, Tri Truss, global truss accessories, store dj, global truss clamps, lighting truss australia, Steel Truss, box truss design, stage design, 290 Flat Truss, Triangular Truss, global truss australia, theatre rigging

F32 Flat Truss Information Sheet

Download

	Title	Type	Size
	F32-FLAT-TRUSS_1	application/pdf	1,004 KB

Additional information

Chord Material	EN AW 6082 T6
Endsocketmaterial	EN AW 6082 T6
Bracing Material	EN AW 6082 T6
Conical Spigot Material	EN AW 2011
Steelpinmaterial	8.8 Grade
Chord Dimension	50mmØ x 2mm
Bracing Dimensions	20mmØ x 2mm
Connectors Included	2 x Conical Spigots, Pins & R-Clips
External Length (mm)	290
External Depth (mm)	50
External Height (mm)	50
Pack Length	310
Pack Depth	60
Pack Height	60
Net weight of the product (kg)	1.2
Pack Weight	1.3
Cubic volume (m³)	0.0011
Product Type	Vertical Junctions
